IPCOAX16 – Nitek International

Overview

The IPCOAX16 is a 16-channel, in-line, Ethernet over Coax surge protector for IP devices. The unit has standard female BNC connectors for connection to coaxial cables and is ideal for rack mounting. The IPCOAX16 provides a heavy-duty, single-point ground connection and is easy to install. It is an excellent surge protector for multi-channel EtherStretch installations.

Features

Heavy-duty single point ground
Provides 16 channels of surge protection
1 pico-Second clamping time
Two-stage Surge Arresting
Supports POE+ Power and Ethernet over Coax

Technical Specs

Connection

Ethernet over Coax (EtherStretch): Standard Female BNC 16-channels

Clamping Voltage

Common Mode (L-G) All: 65-75V
Differential Mode (L-L) Coax: 65-75V

Max Current

Max Continuous Current each conductor: 1.5A
Max CM Surge Current per Conductor: 10kA

Environmental / Temperature

Operating: -40°C to 75°C / -40°F to 167°F
Storage: -40°C to 75°C / -40°F to 167°F
Humidity: Up to 90% non-condensing
Mean Time Between Failure: >100,000 Hours

Mechanical Dimensions (L x W x H)

483mm x 64mm x 23mm / 19″ x 2.5″ x 0.9″

Shipping Dimensions (L x W x H)

Package:
Weight: 5.44kg / 12lbs

Warranty Information

Limited Lifetime Warranty
