VH3200

SKU: P 661955042417 Categories: , Tag:

Modular Card Cage – Black, 1 RU High

Overview

The VH3200 is a 32 port powered video hub with built-in surge suppression and video detection. Systems operate with other Nitek UTP video equipment including, video transceiver hubs, standard video balun transceivers, active transmitters, or any twisted pair equipped camera.

The VH3200 series UTP modular hub system holds up to four VB41x8, TR515x8 or TR560x8 8 channel video receiver cards in any combination, for a total of 32 input ports. The VB41x8 can be used on video runs up to 750 feet (225 meters). The TR515x8 can be used up to 1,500 feet (450 meters) with passive transmitters. The TR560x8 can be used up to 3,000 feet (900 meters) with passive transmitters and up to 6,000 feet (1,800 meters) with the NITEK TT560 active transmitter.

Features

  • Quality video over ordinary twisted pair cable
  • Immunity to noise and interference
  • Built-in surge suppression on VB39 models
  • Passive devices – do not require power
  • Video & P/T/Z over a single pair (with up-the-coax systems)
  • M – version mounts directly to camera or video source
  • Weatherproof design
  • Easy to set up and install
  • Limited Lifetime Warranty
  • Designed, tested, manufactured, and supported in the U.S.A.

Technical Specs

Power Requirements
  • 24VAC, 800mA
Input
  • Low voltage current loop from balanced UTP transmitters
Output-Video
  • 1.0 vpp composite video Monochrome or color
Environmental / Temperature
  • Operating: 0°C to 50°C/ -32°F to 122°F
  • Storage: -40°C to 85°C / -40°F to 185°F
  • Humidity: Up to 95% non-condensing
Mechanical Dimensions (W x H x L)
  • 19″ x 1.75″ x 9.4″
Shipping Dimensions (W x H x L)
  • Package:
  • Weight: 14lbs

Warranty Information

Limited Lifetime Warranty
